General characteristics
| Saw frame | Pivot frame |
| Band dimensions | 3120 mm |
| Band speed | 35/70 m/min |
| Cutting capacity 0° round | 280 mm |
| Cutting capacity 0° square | 240 mm |
| Cutting capacity 0° flat | 350x140 mm |
| Cutting capacity 45° | rund 230 mm, quadrat 200 mm, rechteck 230 x 120 mm |
| Cutting capacity 60° | rund 150 mm, quadrat 130 mm, rechteck 130 x 130 mm |
| Cutting capacity - 45° | rund 200 mm, quadrat 170 mm, rechteck 220 x 110 mm |
| Working height | 830 mm |
Dimensions and weight
| Length | 1550 mm |
| Width | 1400 mm |
| Height | 1750 mm |
| Weight | 420 kg |
Description
manual vice with lever for quick clamping
gravity downfeed with adjustable damper
2 speeds
coolant equipment
digital readout for mitre cuts
