General characteristics
| Saw frame | Pivot frame |
| Band dimensions | 3010x27x0,9 mm |
| Band speed | 35/70 (PLC) m/min |
| Band speed continous | 20-100 (CNC/Touch) m/min |
| Cutting capacity 0° round | 260 mm |
| Cutting capacity 0° square | 240 mm |
| Cutting capacity 0° flat | 330x120 mm |
| Cutting capacity 45° | rund 200 mm, quadrat 190 mm, rechteck 200 x 130 mm |
| Cutting capacity 60° | rund 120 mm, quadrat 115 mm, rechteck 120 x 100 mm |
| Min. rest piece length | 220 mm |
| Working height | 835 mm |
| Hydraulic motor | 0.37 kW |
| Coolant pump motor | 0.12 kW |
Dimensions and weight
| Length | 2800 mm |
| Width | 2050 mm |
| Height | 1900 mm |
| Weight | 1090 kg |
Description
Version PLC: adjustment of material feed by handwheel, counter and limit switch
Version CNC: feed lenght and numbers by CNC (99 progamms)
Version Touch: as CNC but with 7" touchscreen for easier operation
automatic cutting cycle clamping, saw blade and cutting fluid on, cutting operation, saw blade and cutting fluid off, fast return stroke, declamp
automatic feed: PLC 800 mm/stroke, CNC/Touch: 600 mm/stroke
variable cutting pressure.
Machine with 2 cutting speeds (PLC) or speed variator (CNC/Touch)
cutting fluid system
automatic saw blade breakage detection
hydraulic vices
material chute
chip brush
suggested max. diam. in automatic mode for full material: 150 mm
user manual in English or German
Alternatives:
| Model 330 AE CNC | € | 20.490,00 |
| Model 330 AE Touch | € | 22.600,00 |
Further information
Notice
Prices ex location, excluding VAT.
The General Terms and Conditions of Delivery of the Austrian Association of the Machine and Steel Construction Industry apply.
We only sell under retention of title, the goods remain our unrestricted property until they have been paid for in full.
Price changes and errors excepted.
