General characteristics
| Saw frame | Pivot frame |
| Band dimensions | 3270x27x0,9 mm |
| Band speed | 35/70 (PLC) m/min |
| Band speed continous | 20-100 (CNC/Touch) m/min |
| Cutting capacity 0° round | 300 mm |
| Cutting capacity 0° square | 240 mm |
| Cutting capacity 0° flat | 420x200 mm |
| Cutting capacity 45° | rund 240 mm, quadrat 230 mm, rechteck 270 x 140 mm |
| Cutting capacity 60° | rund 170 mm, quadrat 170 mm, rechteck 170 x 170 mm |
| Min. rest piece length | 220 mm |
| Working height | 835 mm |
| Hydraulic motor | 0.37 kW |
| Coolant pump motor | 0.12 kW |
Dimensions and weight
| Length | 3220 mm |
| Width | 2050 mm |
| Height | 1900 mm |
| Weight | 1090 kg |
Description
Version PLC: adjustment of material feed by handwheel, counter and limit switch
Version CNC: feed lenght and numbers by CNC (99 progamms)
Version Touch: as CNC but with 7" touchscreen for easier operation
automatic cutting cycle clamping, saw blade and cutting fluid on, cutting operation, saw blade and cutting fluid off, fast return stroke, declamp
automatic feed 800 mm/stroke
chip conveyer (CNC/Touch)
variable cutting pressure
Machine with 2 cutting speeds (PLC) or speed variator (CNC/Touch)
cutting fluid system
automatic saw blade breakage detection
hydraulic vices
suggested max. diam. in automatic mode for full material: 150 mm
maerial chute
user manual in GERMAN
Alternatives:
| Model 420 A CNC | € | 31.700,00 |
| Model 420 A Touch | € | 33.750,00 |
Further information
Notice
Prices ex location, excluding VAT.
The General Terms and Conditions of Delivery of the Austrian Association of the Machine and Steel Construction Industry apply.
We only sell under retention of title, the goods remain our unrestricted property until they have been paid for in full.
Price changes and errors excepted.
