General characteristics
| Drilling capacy mild steel | 30 mm |
| Spindle cone | MK 3 |
| Distance spindle - column | 250 mm |
| Revs | 65 - 3.060 (8) r.p.m. |
| Column diameter | 100 mm |
| Distance spindle - table | 170 - 660 mm |
| Distance spindle-base | 1.216 mm |
| Table | 300 x 270 mm |
| Base dimensions | 600 x 380 mm |
Dimensions and weight
| Length | 380 mm |
| Width | 600 mm |
| Height | 2060 mm |
| Weight | 260 kg |
Description
ERLO (MADE IN SPAIN)
for manufacturing use
High quality geardrive machine
2 automatical feed
Left-right drilling
Automatic tool ejector
Adjustable depth stop
Table with T-slots
Drill guard with micro switch
Lightening equipment
User manual in English or GERMAN
CE
Option:
coolant equipment with T-slots in base plate ERB € 910,-
Reverse for tapping IR/RS € 810,-
Further information
Notice
Prices ex location, excluding VAT.
The General Terms and Conditions of Delivery of the Austrian Association of the Machine and Steel Construction Industry apply.
We only sell under retention of title, the goods remain our unrestricted property until they have been paid for in full.
Price changes and errors excepted.
