General characteristics
| Grinding lenght | 610 mm |
| Distance spindle - table | 600 mm |
| Table | 610 x 305 mm |
| Grinding area | 610 x 305 x 600 mm |
| Magnetic table | 300 x 600 mm |
| Table movement hydraulic | 650 mm |
| Table movement manual | 700 mm |
| Table speed | 5 - 25 m/min |
| Cross feed | 1.1 m/min |
| Cross feed incremental | 1 - 12 mm |
| Max. cross feed | 370 mm |
| Hydraulic motor | 1.5 kW |
| Cross feed motor | 0.004 kW |
| Feed motor grinding wheel | 0.19 kW |
| Total power | 7 kW |
| Grinding wheel dimensions | 355 x 50 x 127 mm |
| Spindle speed | 1.45 U/min |
| Spindle motor | 3 kW |
| Crossfeed per handwheel revolution | 4 mm |
Dimensions and weight
| Length | 2670 mm |
| Width | 1810 mm |
| Height | 2050 mm |
| Weight | 2100 kg |
Description
control panel on swiveling arm
aut. vertical feed
hardened slide ways in all 3 axes with needle rollers
grinding wheel spindle on 4 high precision angular contact bearings
electro-magnetic chuck
coolant equiptment with aut. paper filter and magnetic separator
manual extractor with diamond
grinding wheel
grinding wheel flange
grinding wheel balancing scale
balance arbor
LED machine lamp
machine and equipment according to the CE-regulations
user manual in GERMAN and ENGLISH
