General characteristics
| Grinding lenght | 610 mm |
| Distance spindle - table | 600 mm |
| Table | 600 x 300 mm |
| Grinding area | 355 x 50 x 127 mm |
| Magnetic table | 600 x 300 mm |
| Max. work piece weight | 420 kg |
| Table movement hydraulic | 700 mm |
| Table speed | 5 - 25 m/min |
| Cross feed | 0 - 2.250 m/min |
| Cross feed incremental | 0,001 - 32 mm |
| Max. cross feed | 350 mm |
| Automatic vertical feed | 440 mm |
| Vertical feed | 0 - 675 mm/min |
| Vertical feed incremental | 0.001 - 0.04 mm |
| Spindle revs | 500 - 2000 rpm |
| Spindle motor | 5 kW |
| Hydraulic motor | 0.75 kW |
| Cross feed motor | 1.1 kW |
| Feed motor grinding wheel | 1.1 kW |
| Table height | 975 mm |
| Maximal table load | 420 kg |
| Grinding wheel dimensions | 355 x 50 x 127 mm |
| Spindle speed | 500 - 2000 U/min |
Dimensions and weight
| Length | 2710 mm |
| Width | 2428 mm |
| Height | 2200 mm |
| Weight | 3500 kg |
Description
10,4" grafic NC-control on swiveling arm with touch screen for:
- seletion of working mode, program creation, graphic condition control, alarm list
aut. vertical feed
servo drive for grinding wheel feed and table cross feed
hardened slide ways in all 3 axes with needle rollers
electro-magnetic chuck
coolant equiptment with aut. paper filter and magnetic separator
autom. dressing attachment table mounted with compensation *
fully enclosed splash guard protection of working area
grinding wheel
grinding wheel flange
grinding wheel balancing scale
balance arbor
LED machine lamp
machine and equipment according to the CE-regulations
user manual in GERMAN and ENGLISH
autom. dressing attachment table mounted with compensation *
Further information
Brochures
Product video
Flat grinding machine FSG-1224AF
