General characteristics
| Grinding lenght | 1200 mm |
| Distance spindle - table | 850 mm |
| Table | 1200 x 500 mm |
| Grinding area | 1200 mm |
| Magnetic table | 1200 500 mm |
| Table speed | 5 - 30 m/min |
| Cross feed | 0 - 5000 m/min |
| Max. cross feed | 560 mm |
| Vertical feed | 0 - 2000 mm/min |
| Vertical feed incremental | 0.001 mm |
| Spindle revs | 500 - 2200 rpm |
| Spindle motor | 11 kW |
| Hydraulic motor | 3.7 kW |
| Cross feed motor | 3.1 kW |
| Feed motor grinding wheel | 2.4 kW |
| Table height | 900 mm |
| Max. workpiece weight on magnetic table | 930 kg |
| Max. workpiece weight on t-slot table | 1250 kg |
| Grinding wheel dimensions | 405 x 50 x 127 mm |
Dimensions and weight
| Length | 4600 mm |
| Width | 2950 mm |
| Height | 2745 mm |
| Transport dimensions | 4610 x 2290 x 2500 mm |
| Weight | 6400 kg |
Description
Smart i control with 10.4" touchscreen on a swiveling panel, with electronic wired handwheel
- RS232, USB I/O connection
- SMART Grind Cam (dxf transfer in G code)
- PC based control with graphical dialog programming or G-code programming
Infinitely variable speed
Surface grinding cycle, cross grinding cycle, plunge grinding cycle, multiple groove grinding cycle, contour grinding cycle, dressing cycle
Spindle with 6 angular contact ball bearings (P4, checkout 7)
Air purge spindle
Longitudinal guides with double V shape, with Turcite-B coating
Transverse and vertical feed with precision ball screws (class C2) and servo motors
Longitudinal feed hydraulically
Linear scale on Y-axis 675mm
Fully enclosed splash guard with lamp
Electromagnetic chuck plate 1200 x 500 mm
Coolant system with automatic paper filter and magnetic separator
automatische Abziehvorrichtung am Tisch montiert, ohne Diamant, mit automatischer Kompensation *
Grinding wheel
Grinding wheel flange
Grinding wheel balancing scale
Heat exchanger for electric cabinet
Machine and equipment in accordance with CE regulations
Operating manual in GERMAN or ENGLISH
Price FOB Taiwan
* The exact configuration of the dresser must be clarified before ordering
Further information
Product video
Flat grinding machine SMART-H2048IV
