General characteristics
pressing capacity | 150 to |
Stroke | 500 mm |
Table | 1250x1000 mm |
Space between columns | 1250x1000 mm |
Daylight | 600 mm |
Rapid speed | 23 mm/s |
Working speed | 4 mm/s |
Motor | 5.5 kW |
Dimensions and weight
Length | 1520 mm |
Width | 1270 mm |
Height | 2500 mm |
Description
4-pillar guide
ram guide round
table and ram with T-slots
2 hand operation
Siemens PLC
manometer
users manual
Light barrier | € | on Request |
Siemens touchscreen-control, 50 programs storeable, for programming: • Upstroke and downstroke quota |
€ | on Request |
Working hour counter | € | on Request |
Stroke counter | € | on Request |
Decompression valve | € | on Request |
Oil cooler with decompreission valve | € | on Request |
Pressur switch | € | on Request |
Further information
Brochures
Notice
Prices ex location, excluding VAT.
The General Terms and Conditions of Delivery of the Austrian Association of the Machine and Steel Construction Industry apply.
We only sell under retention of title, the goods remain our unrestricted property until they have been paid for in full.
Price changes and errors excepted.
