General characteristics
| Revs | 40 -3200 r.p.m. |
| Taper | ISO 40 |
| Working area | 600 x 500 x 400 mm |
| Table | 1000 x 500 mm |
| Motor | 3.75 kW |
| Rapid feed in all 3 axes | 1000 mm/min |
| Clamping slots | 8 |
| Width x Distance | 14 x 63 mm |
| Maximal table load | 300 kg |
| Travel longitudinal | 600 mm |
| Travel cross | 500 mm |
| Travel vertical | 400 mm |
| Feeds stepless X,Y range | 0 - 600 mm/min. |
| Feeds stepless Z range | 0 - 600 mm/min. |
| Horizontal spindle number of rates | 40 - 3200 |
| Vertical spindle number of rates | 40 - 3200 |
| Spindle swivelling | +/- 90° ° |
| Quill travel | 100 mm |
| Clamping of tools | manuell |
| Spindle motor | 3 kW |
| vertical table | 1200 x 250 mm |
| Distance vertical milling spindle - milling table | 160 - 660 mm |
| Distance horizontal milling spindle - milling table | 95 - 495 (2. T-Nut), 180 - 580 (3. T-Nut) mm |
Dimensions and weight
| Weight | 1814 kg |
Description
swiveling operating panel
3 axes digital read out Fagor 400ib Innova
motor for horizontal- and vertical spindle: 3,75 kW
feed motors with inverter for X/Y/Z: 0,75 / 0,75 / 0,75 kW
ball screw spindles for X/Y/Z axes
manual gear box for spindle speeds
1 pc. long milling arbor 27 mm
3 pcs. recustion sleeves (MK1, MK2, MK3)
1 pc. drawing bar ISO40 for horizontal or vertical spindle
spindle protection with switch
table safety guard with doors with switches
outer arbor support for horizontal spindle
LED work lamp
automatic lubrication for X/X/Z guidways
safety hand wheels for X/Y/Z axes
coolant equipment with chip tray
covers for X/Z axes
level pads and bolts
tool box with tools
operating manual in English or German
according to CE rules
