General characteristics
| Grinding wheel dimensions | 250 x 40 x 51 mm |
| Grinding belt dimensions | 1300 x 75 mm |
| Motor | 1 kW |
| Revs | 1400 1/min |
| Grinding belt speed | 15 m/s |
| Connection for dust collector diam. | 42 mm |
Dimensions and weight
| Length | 600 mm |
| Width | 540 mm |
| Height | 1190 mm |
| Transport dimensions | 1200 x 800 x 1000 mm |
| Weight | 70 kg |
Description
With base frame, integrated suction and brake
High performance
Belt grinding device height adjustable 0-90°.
Maximum usable face grinding area
Belt adjustment with fine adjustment
Longitudinal stop for material guide
Perfectly balanced and low vibration
Connection on both sides for dust extraction Ø 50 mm
Motor protection switch with undervoltage release
Fixed stop
1 Sanding belt standard (brown), grit 80
1 grinding wheel 250 x 40 x 51 mm, grit 80
Spark protection
Connection cable with CEE plug
Alternatives:
Version without suction (Art. 330.365)
Version without stand, suction and brake (Art. 330.360)
Further information
Brochures
Product video
Double grinding machine TSB 250 P
