General characteristics
| Cutting length | 2050 mm |
| Max. thickness - mild steel | 6 mm |
| Strokes | 12 - 20 1/min |
| Cutting angle | 0,5 – 3 ° |
| Number of downholders | 13 pcs. |
| Back gauge | 750 mm |
| Motor power | 7.5 kW |
| Table height | 770 mm |
Dimensions and weight
| Length | 2680 mm |
| Width | 1650 mm |
| Height | 1570 mm |
| Weight | 3000 kg |
Description
link motion controlled
Backgauge with handwheel for fine adjustment
Cutting angle adjustment
1 side stop 1000 mm
manual cutting gap adjustment
rear light barrier shield
Knives newly sharpened
backgauge motor 0,37 kW
Operating manual of identical HACO TS in German
Does not comply with German UVV & Austrian AMVO
