General characteristics
| Saw frame | Pivot frame |
| Band dimensions | 3120x27x0,9 mm |
| Band speed | 35/70 m/min |
| Cutting capacity 0° round | 280 mm |
| Cutting capacity 0° square | 240 mm |
| Cutting capacity 0° flat | 370x140 mm |
| Cutting capacity 45° | rund 225 mm, quadrat 215 mm, rechteck 230 x 140 mm |
| Cutting capacity 60° | rund 140 mm, quadrat 140 mm, rechteck 140 x 130 mm |
| Working height | 830 mm |
Dimensions and weight
| Length | 1550 mm |
| Width | 1400 mm |
| Height | 1900 mm |
| Weight | 353 kg |
Description
manual vice with lever for quick clamping
gravity downfeed with adjustable damper
2 speeds
coolant equipment
