Motorized plate shear HESSE by DURMA MS 2004
| Model | MS 2004 |
| Brand | HESSE by DURMA |
| Condition | new |
| Max. thickness - mild steel | 4 mm |
| Cutting length | 2050 mm |
| Origin | Türkiye |
General characteristics
| Cutting length | 2050 mm |
| Max. thickness - mild steel | 4 mm |
| Strokes | 42 1/min |
| Back gauge | 750 mm |
| Motor power | 7.5 kW |
| Table height | 800 mm |
| Table width | 450 mm |
Dimensions and weight
| Length | 2700 mm |
| Width | 2300 mm |
| Height | 1350 mm |
| Weight | 2800 kg |
Description
motorized back gauge at recirculating ballscrew with Control DT5
hold down with rubber pads
Side Lay with T-Slot
2 Sheet support arms
ball in the table
tape measure
tilting stop
light barriers on the back of the machine
cutting line illumination
user manual in GERMAN and ENGLISH
Further information
Brochures
Product video
Motorized plate shear MS 2004
