Electric CNC press brake HESSE by DURMA AD-ES 2040
| Model | AD-ES 2040 |
| Brand | HESSE by DURMA |
| Condition | new |
| pressing capacity | 40 to |
| Bending length | 2050 mm |
| Origin | Türkiye |
General characteristics
| pressing capacity | 40 to |
| Bending length | 2050 mm |
| Axes | Y1 / Y2 / X and R axis |
| Stroke | 200 mm |
| Inside distance between side frames | 1700 mm |
| Gap in side frame | 350 mm |
| Daylight | 440 mm |
| Power concept | servomotorized spindle drive |
| rapid speed Y-axis | 180 mm/s |
| Working speed Y-axis | 10 |
| Retractionspeed Y-axis | 115 |
| Back gauge travel X-axis | 650 mm |
| Back gauge travel R-axis | 250 mm |
| Table height | 900 mm |
| Motor power | 7.2 kW |
Dimensions and weight
| Length | 2600 mm |
| Width | 1450 mm |
| Height | 2650 mm |
| Weight | 4400 kg |
Description
standard equiptment:
servomotorized spindle drive
4 axes (Y1, Y2, X and R)
Color graphics control DELEM DA-66S
- 17 " Touchscreen
- 3D imaging in simulation and production
- Suitable for personal Windows applications
- Compatible with DelemModusys
- USB and peripheral interface
- Skill-specific application treatment
- Sensor, bending and correction interface
servo motorized back gauge on linear guides and ball screws
CNC crowning table
upper tool 1010 / A / 75 °, devided and cranked
4-V die block 60x60 2009 (V = 16,22,35 and 50 mm)
laser safety device Fiessler AKAS mounted on the upper beam
linear guided sheet support arms
according to CE rules
users manual in English or German
Advantages of this concept:
- higher productivity as classic hydraulic press brakes,
by nearly instantaneously reaction on foot pedal signal
- low energy consumption
- compact motor-spindle unit with small amount of components
- no hydraulic components
optional equipment:
| Z1/Z2-axes | ||
| CNC control DELEM DA-69S 3D incl. PC software Profile-S with 3D file import option | ||
| Quick release clamping for upper tool |
