General characteristics
| Punching power | 110 ton |
| Throat depth | 500 mm |
| Max. diameter at sheet thickness (mild steel) | 40x20 mm |
| Max. number of strokes at 20 mm stroke | 28 1/min |
| Motor | 9 kW |
Dimensions and weight
| Length | 2080 mm |
| Width | 1300 mm |
| Height | 2050 mm |
| Weight | 3150 kg |
Description
hydraulic drive
table with gauge
user manual in GERMAN and ENGLISH
CNC options on request
We have a big stock of punches and dies for immediate dispatch
We have more than 700 references!
