General characteristics
| Punching power | 130 ton |
| Throat depth | 600 mm |
| Number of stations | 5 |
| Cylinder | 2 |
| Max. diameter at sheet thickness (mild steel) | 50x18 mm |
| Stroke | 80 mm |
| Flat steel | 600x18 (max. 600x20 mit Deformation) mm |
| Angle steel | 120x120x11 (max. 150x150x15 mit Deformation) mm |
| Round / square steel | 45/40 mm |
| Notcher | 130x12 mm |
| Bending unit | 250x12 mm |
| Motor | 15 kW |
Dimensions and weight
Description
hydraulic drive
2 foot pedals for independant working on punching and section station
bending unit with 2 dies, V50 and V90
flat steel station with device for reducing deformation
angle iron station with round and square bar cutting
triangular notching station with table and gauge
punching station with table and gauge
gauge 1000 mm with contact switch, for angle / flat steel station
operating manual in German and Englisch
